Fluke 15B+ Digital Multimeter

16,800

Brand Fluke
Power Source Battery Powered
Style Digital
Color Orange
Item Weight 300 Grams

16,800

Buy Now
Add to cart

19 / 100



Product Description

New Feature: Faster response Greater capacitance range: 0.01nF ~ 1000μF The more bright: Add white LED backlight Larger screen: Larger than the original 1.5 times Maximum Voltage between any Terminal and Earth Ground: 1000 V Display(LCD)…………………………………………..4000 counts,updates 3/sec Battery Type……………………………………………2 AA,NEDA 15A, IEC LR6 Battery life……………………………………………….500 hours minimum(50 hours in LED Test mode without load. The hours with load depends on the type of LED under test) Temperatuer Operating…………………………………………………0 deg to 40 deg Storage…………………………………………………….-30 deg to 60 deg Relative Humidity Operating Humidity…………………………………Non-condensing≤90%at 10deg to 30deg;≤75% at 30deg to 40deg Operating Humidity,40MC Range…………..≤80% at 10deg to 30deg;≤70% at 30deg to 40deg Altitude Operating…………………………………………………2000m Storage…………………………………………………….12.000m Temperature Coefficient…………………………0.1×(specified accuracy)/deg(<18deg or > 28deg) Fuse protection for current inputs…………440 mA,1000 V Fast Fuse, Fluck specified part only. 11A,1000v Fast Fuse Size(H×W×L)……………………………………………183×91×49.5(mm) Weight……………………………………………………..455g IP Rating………………………………………………….IP 40 Safety………………………………………………………IEC 61010-1, IEC61010-2-030 600V CAT Ⅲ,1000V CATⅡ,Pollution Degree 2 Electromagnetic Environment……………….IEC 61326-1:Portable Electromagnetic Compatibility………………Applies to use in Korea only

Features

19 / 100

* Count: 4000
* AVG responding
* Voltage: DC: 1000 volts; AC: 1000 volts; DC Accuracy: ± 0.5% + 3 digit; AC Accuracy: ± 1% + 3 digit
* Current: DC: 10 amps; AC: 10 amps; DC Accuracy: ± 1.5% + 3 digit; AC Accuracy: ± 1.5% + 3 digit
* Resistance: 40 M ohm; Resistance Accuracy: ± 1.5% + 3 digit
* Capacitance: 1000 μF; Capacitance Accuracy: ± 5% + 5 digit
* CAT III 600 volts safety rating
* 50 percent bigger display with bright white backlight
* Voltage, resistance, continuity, capacitance measurement
* Input terminal for AC and DC current measurements upto 10 A current
*Diode test, data hold, min/max

Specifications

19 / 100



Brand Name Fluke
EAN 0069596967272
Item Weight 455.0  grams
Model Number FLUKE-15B+/IN CATIII
Number of Items 1
Part Number 4404210
UNSPSC Code 41110000
UPC 069596967272

Details

19 / 100

Technical Details
