UNI-T Ut195E Professional Multimeter
UNI-T Ut195E Professional Multimeter
₨28,175
UT195 series are handheld industrial digital multimeters with IP65 and 2m drop proof. Compare with traditional multimeters, UT195’s troubleshooting capability, resolution, and precision are improved to find issues related to motor drive, factory equipment maintenance, electrical distribution, and repair etc. It is exquisitely designed and easy to operate.
Buy Now
Add to cart
| Weight | 1.5 kg |
|---|
Basic Features
- 1. IP65 rating, 2m drop proof, CAT III 1000V, CAT IV 600V
- 2. Large 6000-count LCD screen
- 3. True RMS
- 4. ACV 750V 5kHz bandwidth
- 5. Flashlight
- 6. Auto LCD backlight controlled by light sensor (can be turned off)
- 7. LoZ voltage test, for ghost voltage measurement
- 8. 20A current measurement (max 30 seconds)
- 9. 31 analog bar
Tech. Spec
Specifications | Range | Best Accuracy |
| Model | UT195E | |
| DC voltage | 600mV ~ 1000V | ±(0.5%+3) |
| AC voltage | 600mV ~ 750V | ±(0.7%+3) |
| LoZ ACV | 600.0V | ±(2.0%+3) |
| DC current (A) | 600.0μA ~ 20A | ±(0.8%+3) |
| AC current (A) | 600.0μA ~ 20A | ±(1.0%+3) |
| Resistance (Ω) | 600.0Ω ~ 60.00MΩ | ±(0.8%+2) |
| Capacitance | 6.000nF ~ 60.00mF | ±(3%+5) |
| Frequency | 60.00Hz ~ 10.00MHz | ±(0.1%+4) |
| Duty ratio | 0.1% ~ 99.9% | ±(2.0%+5) |
Features | ||
| Display count | 6000 | |
| Display interface (HTN) | Single display | |
| Measurement sampling rate | times/s | 3 |
| Analog bar sampling rate | times/s | 10 |
| Analog bar | 31 bars | √ |
| True RMS | √ | |
| AC voltage frequency response | 45 ~ 400Hz | |
| AC current frequency response | 45 ~ 400Hz | |
| Diode/Continuity test | 3.5V | |
| Auto/Manual range | √ | |
| Auto power off | √ | |
| Continuity buzzer | √ | |
| Low battery indication | √ | |
| Data hold | √ | |
| MAX/MIN | √ | |
| Function selection | √ | |
| Flashlight | √ | |
| Auto backlight | √ | |
| Operating temperature | 0 °C ~40 °C | |
| 2m drop tes | √ | |
| Safety rating | IP65 | |
General Characteristics | ||
| Power supply | 9V battery (6F22/6LR61) | |
| LCD size | 66mm×51mm | |
| Device color | Red and grey | |
| Device weight | 450g | |
| Device size | 206.5mm×95.5mm×61mm | |
| Standard accessories | Test probes, battery, carrying bag | |
| Standard individual packing | Standard individual packing Gift box, blister, user manual | |
| Standard quantity per carton | 10pcs | |
| Standard carton size | 605mm×335mm×405mm | |
| Standard carton gross weight | 11.8kg |
Models & Comparison
Specifications | Range | Best Accuracy | ||
| Model | UT195E | UT195M | UT195DS | |
| DC voltage | 600mV ~ 1000V | ±(0.5%+3) | ±(0.5%+3) | ±(0.5%+3) |
| AC+DC | 6.000V ~ 600V | ±(1.5%+4) | ||
| AC voltage | 600mV ~ 750V | ±(0.7%+3) | ±(0.7%+3) | ±(0.7%+3) |
| LoZ ACV | 600.0V | ±(2.0%+3) | ±(2.0%+3) | ±(2.0%+3) |
| DC current (A) | 600.0μA ~ 20A | ±(0.8%+3) | ±(0.8%+3) | ±(0.8%+3) |
| AC current (A) | 600.0μA ~ 20A | ±(1.0%+3) | ±(1.0%+3) | ±(1.0%+3) |
| Resistance (Ω) | 600.0Ω ~ 60.00MΩ | ±(0.8%+2) | ±(0.8%+2) | ±(0.8%+2) |
| Capacitance | 6.000nF ~ 60.00mF | ±(3%+5) | ±(3%+5) | ±(3%+5) |
| Frequency | 60.00Hz ~ 10.00MHz 60.00Hz ~ 10.00MHz | 60.00Hz ~ 10.00MHz | 60.00Hz ~ 10.00MHz | 60.00Hz ~ 10.00MHz |
| Duty ratio | 0.1% ~ 99.9% | ±(2.0%+5) | N/A | ±(2.0%+5) |
| Temperature (°C) | -40 ~ 1000°C | ±(1.5%+4°C | ||
| Temperature (°F) | -40 ~ 1832°F | ±(2.0%+5°F) | ||
| Peak hold | 250μs | |||
Features | ||||
| Display count | 6000 | 6000 | 6000 | |
| Display (HTN) | Single | Single | Single | |
| Measurement sampling rate | times/s | 3 | 3 | 3 |
| Analog bar sampling rate | times/s | 10 | 20 | |
| Analog bar | √ | √ | √ | |
| AC voltage frequency response | 45 ~ 400Hz | 45 ~ 1kHz | 45 ~ 5kHz | |
| AC current frequency response | 45 ~ 400Hz | 45 ~ 1kHz | 45 ~ 5kHz | |
| 3-phase motor sequence test | 600.0V | √ | √ | |
| Low pass filter test | √ (1kHz 3dB attenuation | √ | ||
| Diode/Continuity test | 3.5V | 3V | 3V | |
| Auto/Manual range | √ | |||
| Auto power off | √ | |||
| Continuity buzzer | √ | |||
| Low battery indication | √ | |||
| Data hold | √ | |||
| Max/Min | √ | |||
| Function selection | √ | |||
| Flashlight | √ | |||
| Auto backlight | √ | |||
| Operating temperature | 0 °C ~40 °C | |||
| 2m drop test | √ | |||
| Safety rating | IP65 | |||
General Characteristics | ||||
| Power | 9V battery (6F22/6LR61) | |||
| LCD size | 66mm×51mm | |||
| Device color | Red and grey | |||
| Device weight | 450g | |||
| Device size | 206.5mm×95.5mm×61mm | |||
| Standard accessories | Test probes, battery, carrying bag, temperature probe (UT195M), PC software CD (UT195DS) | |||
| Standard individual packing | Blister, gift box, manual | |||
| Standard quantity per carton | 10pcs | |||
| Standard carton measurement | 605mm×335mm×405mm | |||
| Standard carton gross weight | 11.8kg |
