UT219P AC Digital Power Clamp Meter

UT219P is an intelligent, handheld, and stable power and harmonics clamp meter, with the functions of a digital ammeter and power meter. It can measure harmonics, 3-phase unbalanced voltage, AC voltage, AC current, power, power factor, and more.

Weight	0.95 kg

Basic Features

79 / 100

1. LoZ input for ghost voltage measurement
2. Flashlight and auto backlight

Specification

79 / 100

Specifications	Range	Accuracy
AC current (A)	1000A	±(1.5%+3)
AC voltage (V)	1000V	±（0.7%＋3）
Power (single phase)	1000KW	±（1.7%+5）
Power (3-phase & 3-wires)	1732KW
Power (3-phase & 4-wires)	3000KW
Power frequency (Hz)	15Hz～1000Hz	±（0.3%+3）
Phase angle (-180°~ 179.9°)	15Hz～40Hz	±5°
	40Hz～70Hz	±3°
	70Hz～1000Hz	±5°
Power factor	-1 ~ 1	based on the Accuracy of the Phase angle
Features
Jaw opening	75mm
Phase detection	√(80V~1000V)
	Positive and Negative
AC/DC PEAK measurement	√
Harmonic measurement	32 times
Display mode	LCD screen
	4 kinds of results at the same time
Display count	9999
Bluetooth app	√
True RMS	√
Overload indication	√
High voltage indication	√
High voltage overload warning	√
Low battery indication	√
Data hold	√
Auto power off	Around 15 minutes
Max/Min	√
Overvoltage category	CAT III 1000V/CAT IV 600V
Certificate	CE, UKCA, cETLus

Features

79 / 100

Certificates: CE, ETL, REACH, FCC

● 1000A AC current measurement

● 1000V AC voltage measurement

● AC and DC PEAK measurement

● Three-phase power measurement (up to 3000kW)

● Harmonic/THD/Power Factor/Phase Sequence Measurement

● Single Phase power measurement

● Large pliers head (up to 75mm diameter)

● True RMS measurement

● Bluetooth 5.0

● CAT III 1000V/CAT IV 600V

● IP54
