UT58B Universal Digital Multimeter
Uni Trend’s UT58B is a popular general-purpose multimeter in the mid-budget price point. The Display on the UT58B is 2000-count and large for the meter Palm-size UNI-T digital Multimeter is able to measure high voltage, amperage, resistance, capacitance, and frequency, as well as temperature. The UNI-T UT58B General DMM mostly suits those with some familiarity with multimeters as it is a manual ranging meter. One of the most apparent features of Pocket-size Multitasker is its ability to measure 20A for AC and DC current. Although stated as temporary, this is still a bold claim as the high current input is unfused. In addition, it’s CATIII 600V rating might also be a bit reaching. However, Portable Digital MultiTester UT58B also has a generous resistance range – up to 200MΩ – and can do frequency and capacitance, making it fairly suitable for electronics work The UNI-T UT58B takes its time to measure larger capacitors, and while there is a function for measuring transistor gain, this is seldom used. You can also check for continuity and test current drop across diodes on the same range – it has an audible beeper. The temperature feature of Handheld DMM UNI-T UT58B is a big plus, with a stated range from -40°C to 1,000°C. There is no Fahrenheit setting, unfortunately, but a Type-K thermocouple cable and an adapter plug come included with the multimeter. In addition, the adapter has insertion sockets for quickly testing capacitors and transistors.
2000 display count, refresh rate 2~3 times/s
Function symbols and test lead connection indication
Temperature measurement mode, with K-type temperature probe
Diode and continuity buzzer; auto power off； overload protection
Data hold; 20A AC/DC current measurement
