UT60S True RMS Digital Multimeter

Sold: 0

5,250

UT60 series digital multimeters provide True-RMS measurement, 9999-count resolution, non-contact voltage detection and many convenient features for users’ testing needs. These auto-ranged meters can measure up to 1000V AC/DC voltage, 10A AC/DC current and 100MΩ resistance. The easy-to-use interface with backlight enables you to detect equipment quickly even in dark places. This CE certified meter meets CAT II 1000V/CAT III 600V safety rating with rugged double-injection housing.

5,250

Buy Now
Add to cart

Specifications

19 / 100
Specifications Range UT60S
DC Voltage 9.999mV/99.99mV/999.9mV/9.999V/99.99V/999.9V ±(0.5%+3)
AC Voltage 9.999mV/99.99mV/999.9mV/9.999V/99.99V/999.9V ±(0.8%+3)
DC Current 999.9uA/999.9mA/9.999A/10A ±(0.8%+3)
AC Current 999.9uA/999.9mA/9.999A/10A ±(1.0%+3)
Resistance 999.9Ω/9.999kΩ/99.99kΩ/999.9kΩ/9.999MΩ/99.99MΩ ±(0.8%+2)
Capacitor 9.999nF/99.99nF/999.9nF/9.999μF/99.99μF/999.9μF/9.999mF ±(4.0%+5)
Frequency 99.99Hz~9.999MHz ±(0.1%+5)
Duty Cycle 0.1~99.9% ±(3%+5)
Temperatue –40℃~1000℃/–40°F~1832°F ±4℃/±5℉
Features
Display Count 9999
Auto Range
REL
NCV
Diode
Continuity Test
Acousto-optic Indication (NCV/continuity/battery power)
Low Battery Indication ≤3.6V
Data Hold
Auto Power Off 15Min
Operation Temperature 0℃~40℃
Safety CATII 1000V/CATⅢ 600V

Features
