UNI-T Ut61B+ 1000V True Rms Digital Multimeter

12,600

UT61+ series are reliable true RMS digital multimeters with display counts 6000 (UT61B+/D+) and 22,000 (UT61E+). It can measure up to 1000V AC/DC.

Equipped with audible and visible alarm, this series can provide warning expecially when measuring high voltage/current and temperature.

12,600

Buy Now
Add to cart
81 / 100

UNI-T Ut61B+ 1000V True Rms Digital Multimeter

UT61+ series are reliable true RMS digital multimeters with display counts 6000 (UT61B+/D+) and 22,000 (UT61E+). It can measure up to 1000V AC/DC.

Equipped with audible and visible alarm, this series can provide warning expecially when measuring high voltage/current and temperature.
Models in UT61+ series: UT61B+, UT61D+, UT61E+
Weight1 kg

Features

81 / 100

● True RMS

● Data hold/backlight
● Max/Min/Relative mode
● USB communication
● Input protection
● Diode/continuity test
● NCV (audible/visual alarm)

Specifications

81 / 100

Specifications of UT61+ Series 1000V True RMS Digital Multimeters

SpecificationsRangeUT61B+UT61D+UT61E+
AC voltage (V)1000V±(1%+3)±(1%+3)±(0.8%+10)
DC voltage (V)1000V±(0.5%+3)±(0.5%+3)±(0.05%+5)
AC current (A)10A±(1.2%+5)
20A±(1.2%+5)±(0.8%+10)
DC current (A)10A±(1%+2)
20A±(1%+2)±(0.5%+10)
Resistance (Ω)60MΩ±(1%+2)±(1%+2)
220MΩ±(0.5%+10)
Capacitance (F)60mF±(3%+5)±(3%+5)
220mF±(3%+5)
Frequency (Hz)10MHz±(0.1%+4)±(0.1%+4)
220MHz±(0.01%+5)
Duty cycle (%)0.1%~99.9%±(2%+5)±(2%+5)±(2%+5)
Temperature (℃/℉) -40℃~1000℃±(1%+3)
 -40℉~1832℉±(1%+6)
Display count6000600022000
Bandwidth (Hz)40Hz~500Hz40Hz~1kHz40~10kHz
LPF ACV
LoZ ACV
ACV+DCV
Transistor hFE
Peak Hold
Analog bar313146
General Characteristics
Power1.5V battery (R03) x 4
Product net weight350g
Product size190mm x 90mm x 50mm
Standard accessoriesBattery, gold plated test leads, USB cable, temperature probe (UT61D+),
multi-purpose socket (UT61E+), English manual
Standard individual packingGift box, cloth bag
Standard quantity per carton20pcs
Standard carton measurementUT61+ series: 480mm x 370mm x 365mm
Standard carton gross weightUT61+ series: 15.2kg
Optional accessoriesBluetooth/APP

Applications

81 / 100
UT61E+ Voltage Measurement

Voltage measurement

UT61E+ NCV Measurement

NCV measurement

UT61E+ Resistance Measurement

Resistance measurement

UT61E+ Capacitance Measurement

Capacitance measurement
