Features

Name: UT620C+ Micro-ohmmeter - Variety House
Brand: Micro-ohmmeter
Price: 43125 PKR
Availability: InStock

1. Micro-ohm level measurement, resistance measurement range: 0.001mΩ～300.0KΩ

2. Resolution up to 1μΩ

3. The accuracy can reach ±0.1%FS

4. The measurement current ≤ 1A

5. 500 groups of data storage

6. Large LCD display

7. Automatic shutdown, longer standby time

8. The lithium battery can be used repeatedly

9. Compact design, easy to carry and operate

Specifications

64 / 100

Specification
Resistance range	100.1kΩ~300.0kΩ/3uA	100Ω
	10.01kΩ~100.00kΩ/3uA	10Ω
	1.001kΩ~10.000kΩ/10uA	1Ω
	100.1Ω~1000.0Ω/100uA	0.1Ω
	10.01Ω~100.00Ω/1mA	0.01Ω
	1.001Ω~10.000Ω/10mA	0.001Ω
	100.1mΩ~1000.00mΩ/100mA	0.1mΩ
	0.001mΩ~100.00mΩ/1A	0.01/0.001mΩ
Features
Functions	Measuring the resistance of all kinds of wires, switches, connectors, contactors, fuses, coils, transformer windings, metal riveting, and so on.
Measurement methods	Four-wire method
Test current	≤1A
Open circuit voltage	≤4.2V
Input protection	≤36V AC/DC
Power consumption	measurement power: ≤8W
Measuring speed	about 2times/s
Automatic power off	15 minutes if no operation
storage	500 set
display type	segment LCD
USB ingerface	Type C
Backlight	Yes
Low battery indication	Yes
IP rating	IP54
Certificate	CE, RoHS
