UNI-T Utp3305Tfl-Ii Dc Supply
UNI-T Utp3305Tfl-Ii Dc Supply
₨63,250
UTP3000 Series are three-channel linear DC power supplies of adjustable
dual channel and fixed single-channel output, featuring tracking,
constant voltage/current, series/parallel output, temperature
controlled cooling fan, and over-voltage/current protection.
Buy Now
Add to cart
UNI-T Utp3305Tfl-Ii Dc Supply
| Weight | 1 kg |
|---|
Specification
| Specifications | ||
| Model | UTP3305 | |
| Output voltage | CH1, CH2 | 0~32V |
| CH3 | 5V | |
| Output current | CH1, CH2 | 0~5A |
| CH3 | 3A | |
| O utput power | 335W | |
| Load regulation | CV≤1×10-4 +3mV, CC≤2×10-4 +3mA | |
| Ripple and noise | CV≤1mVrms; CC≤3mArms | |
| Output regulation resolution | CV: 100mV (typical), CC: 10mA (typical) | |
| Tracking bias | 5×10-3 +10mV | |
| Reliability | MTBF(e): ≥2000hrs | |
| Display mode | 3-bit voltage and current dual display | |
| Features | Auto conversion of constant voltage and current with current limit protection; CH1 and CH2 master-slave tracking in series | |
| General Characteristics | ||
| Power | Input voltage: 115V AC/230V AC; Frequency: 47Hz~63Hz | |
| Product color | White and grey | |
| Product net weight | 10kg | |
| Product size | 260mm x 170mm x 315mm | |
| Standard accessories | Power cord, output cables | |
| Standard individual packing | Carton box, English manual | |
