Yihua YH-1502T Dc Variable Power Supply
Yihua YH-1502T Dc Variable Power Supply
Ships In: 1-3 Days
Delivery Area: Nationwide
Shipped By: Variety House
Machine :1
Manula :1
Power Cable :1
- Inner box size 27*14*22CM
- Outer carton box size 76*29*46.5CM
- Q’TY 10PCS/CTN
- Goods net weight 1.9KG/PC
- Outer carton weight 20KG
CHARACTERISTIC
1. High accuracy and reliability
2. Short circuit protection and automatic recovery function
3.Dual LED displays to show current and voltage.High-performance mobile phone repair equipment that is both affordable and easy to operate.
PARAMETERS
| Parameters | |
| Rated voltage | AC220V±10% 50Hz |
| Operating environment | 0～40℃ relative humidity＜80％ |
| Storage temperature | －20～80℃ relative humidity＜80％ |
| Dimensions of the machine body | 27*14*22cm |
| Weight | 1.9KG |
| Performance parameters | |
| Output voltage | Adjustable continuously within 0～15V |
| Output current | Adjustable continuously within 0～2A (current limitation adjustment when above 0.2A) |
| Output power | 15W |
| Source effect | ≤1mV |
| Load effect | ≤0.33% |
| Ripple noise | ≤3mVrms（5Hz ~ 1MHz）/≤3mArms |
| Display accuracy | 0.1V/0.1A/1mA |
| Protection mode | Over-current, short circuit, over-temperature protection |
| Dissipation mode | Air cooling |
