Digital Ac Dc Clamp Meter T26A

2,063

  1. Model: T-26A
  2. Max.Dispaly:2000
  3. Battery type: 2 x 1.5V AAA Battery(not included)
  4. Automatic power-off: yes
  5. DC voltage:
    • Range: 600V
    • Accuracy: ±(1%+5)

2,063

Buy Now
Add to cart
SKU: DGL-T26A Category: Brand:
82 / 100

Digital AC DC Clamp Meter T26A

The T 26A is a Digital Clamp Meter that can measure AC currents up to 400 A, and AC and DC voltages up to 600 V. portable Clamp Ampere Meter has four range settings of 2 KΩ, 200 KΩ, 2 MΩ, 20MΩ for measuring resistance. The handheld AC/DC Clamp tester also has a live wire test function, during which time an LED lights to indicate a live wire. This is a basic Digital Tong Tester and therefore has the diode testing function, continuity testing, or buzzer.T26A Clamp Multitester is a perfect tool for the laboratory, factory, and home.

  • Multifunctional, can measure AC/DC voltage, AC current, resistance, capacitance, diode, and temperature.
  • Stable performance, high precision, and response quickly.
  • Large LCD screen, easy to read.
  • Low battery indication, overload protection.
  • Data hold, buzzer indication.
  • The max display size of 2000
Weight0.3 kg

Features

82 / 100
  • Multifunctional, can measure AC/DC voltage, AC current, resistance, capacitance, diode, and temperature.
  • Stable performance, high precision, response quickly.
  • Large LCD screen, easy to read.
  • Low battery indication, overload protection.
  • Data hold, buzzer indication.
  • The max display size of 2000

Specifications

82 / 100
  1. Model: T-26A
  2. Max.Dispaly:2000
  3. Battery type: 2 x 1.5V AAA Battery(not included)
  4. Automatic power-off: yes
  5. DC voltage:
    • Range: 600V
    • Accuracy: ±(1%+5)
  6. AC voltage:
    • Range:600V
    • Accuracy: ±(1.5%+5)
  7. AC current:
    • Range:200A/400A
    • Accuracy: ±(2.5%+5)
  8. Resistance:
    • Range: 200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ
    • Accuracy: ±(1.2%+5)
  9. Temperature:
    • Range: -30~1000℃
    • Accuracy:±(3%+4)/±(3%+15)
  10. clamp opening Diameter: 30mm
  11. Continuity: <50Ω buzzer sounds.
  12. Item size: 214 x 111 x 40mm
  13. Item weight:135g
