ET829 3 in 1 Oscilloscope Multimeter 80MHZ Dual Channel Oscilloscope and Multimeter and Generator
ET829 3 in 1 Oscilloscope Multimeter 80MHZ Dual Channel Oscilloscope and Multimeter and Generator
₨40,000
Item Type: Oscilloscope Multimeter
Screen: 320 x 240 resolution, 2.8in TFT color screen, 58 x 45mm / 2.28 x 1.77in (approx.).
Backlight Brightness: Adjustable
Buy Now
Add to cart
ET829 3 in 1 Oscilloscope Multimeter 80MHZ Dual Channel Oscilloscope and Multimeter and Generator
Red – ET829
White – ET202D
Same functions,different color
Digital Storage Oscilloscope multimeter signal generator 3 in 1 !!!
- 80MHz bandwidth + 250MSa/s sampling rate + 2 channels
- Sine, square, triangle, waveforms output
- 6000 counts universal True RMS multimeter function
| Weight | 1 kg |
|---|
Features
– 3in1Function,80MHz digital storage oscilloscope (DSO) + 6000counts large capacitance True RMS RMS multimeter (DMM) + 1Hz ~ 5MHz signal generator
– The oscilloscope has a real-time sampling rate of 250MSa/s, 80MHz analog bandwidth and 2-Channel
– Intuitive prompt operation steps, key function and measurement status, user-friendly interface and simple operation
– Auto Measure, DSO realizes one-key AUTO measurement, automatic display of measurement waveform and automatic zero correction
– Storage,up to 200 DSO waveforms and 2000 groups of DMM values are stored/read, and 2000 groups of data are automatically recorded for on-line IC detection
– Signal generator,produce sine wave, triangle wave, square wave signal,frequency, amplitude can be set independently.Work with oscilloscope function at the same time, constitute a test system
– 2.8inch TFT color screen,320X240 resolution with adjustable LED backlight
– Built-in 2*18650 lithium rechargeable batteries, support 15W fast charging,10 hours long using time
-PC software, to realize timing measurement, curve drawing, waveform analysis and FFT transformation
– Innovative waveform preview window ,to see the overall waveform of the waveform being measured
– Accurate measurement ,using Panel Calibration Technology, memory all calibration data, without any potentiometer adjustment
– Multifunctional Design:3 Trigger Modesof Auto, Normal and Single,relative value, data hold, afterglow selection, self-calibration function,cursor function, etc.
– Wide applications: Suitable for electric occasions such as automobile maintenance and power maintenance.
Specifications
Name: 3in1 Oscilloscope
Material: ABS
General characteristics:
Display resolution: 320 (horizontal) * 240 (vertical) pixels
Display size: 2.8inch TFT color screen diagonally
Display backlight time: adjustable
Display backlight brightness: adjustable
Power supply: AC100V-240V, 50Hz/60Hz; DC15W quick charging
Power consumption of the whole machine: Oscilloscope range≤400mA, multimeter range≤200mA
Battery: 18650 lithium battery 2000mAh x 2 (included)
Battery level indicator: Yes
Auto sleep: the time can be adjusted or turned off, and there will be a sound or display prompt before sleep.
Sound prompt: On/off optional; there are various kinds of voice prompts, such as button sound, high pressure or over-range alarm sound during measurement, and some AI voices that may be added, etc. To turn off the sound, you can choose to turn off the sound of the whole machine, or just turn off a selected prompt sound.
Use time: about 10 hours for oscilloscope range, about 20 hours for multimeter ranges
Operating environment: 0℃〜40℃, <75%RH
Storage conditions: -10℃~60℃, <90%RH
Item size: 100 * 210 * 40mm / 3.94 * 8.27 * 1.57in
Item weight: 480g / 1.06lb
