LM555LD Laser Leveler

19,800

UNI-T's new LM555LD laser level enables you to locate horizontal line, vertical line, and V-H cross-point accurately. The new and improved laser level is a perfect tool for building construction, home decoration, renovation, furniture installation, flooring, and project layout.

19,800

Buy Now
Add to cart

Weight 10.71 kg

Basic Features

12 / 100

● IP54 water proof

● Self leveling
● Built-in Li-ion battery
● Working radius: 20m

Tech. Spec

12 / 100
Specifications LM555LD
Display type Green LD
Line type 4V1H 1D
Laser wavelength 510~515nm
Light source ≤1mW
Laser class 2
Expanded Angle H130°/V110°
H/V accuracy ±2mm/10m
Self-leveling range ±3.5°
Self-leveling method Gravity pendulun magnetic damping
Self-leveling time <3s
Working distance Line 20m, point [email protected]
Operating time >5h (all lasers on)
Operating temperature range  -5°C to 40°C
Storage temperature range  -20°C to 60°C
IP rating IP54
GENERAL CHARACTERISTICS
Power 3.7V Li-ion battery 4000mAh
Product net weight Around 1kg
Product size 126mm x 120mm x 204.5mm
Standard accessories Safety goggles, adapter, USB cable, mark ruler, English manual
Standard individual packing Gift box, tool box
Standard quantity per carton 4pcs
Standard carton measurement 505mm x 415mm x 285mm
Standard carton gross weight 9.1kg



Model & Comparison

12 / 100
Specifications LM555LD
Display type Green LD
Line type 4V1H 1D
Laser wavelength 510~515nm
Light source ≤1mW
Laser class 2
Expanded Angle H130°/V110°
H/V accuracy ±2mm/10m
Self-leveling range ±3.5°
Self-leveling method Gravity pendulun magnetic damping
Self-leveling time <3s
Working distance Line 20m, point [email protected]
Operating time >5h (all lasers on)
Operating temperature range  -5°C to 40°C
Storage temperature range  -20°C to 60°C
IP rating IP54
GENERAL CHARACTERISTICS
Power 3.7V Li-ion battery 4000mAh
Product net weight Around 1kg
Product size 126mm x 120mm x 204.5mm
Standard accessories Safety goggles, adapter, USB cable, mark ruler, English manual
Standard individual packing Gift box, tool box
Standard quantity per carton 4pcs
Standard carton measurement 505mm x 415mm x 285mm
Standard carton gross weight 9.1kg
