MCH 303A DC Power Supply 0-30V/3A

Add to cart

MCH 303A DC Power Supply 0-30V/3A

SKU: MCH-303A Categories: Brand:
82 / 100
Powered by Rank Math SEO

MCH 303A DC Power Supply 0-30V/3A

90W 30V 3A Variable DC Power Supply, Variable Single Channel Linear Type Digital DC Power Supply with RoHS and CE

MCH Industrial Supply, single output, 30V/3A, model MCH-303A

Specifications:

Specification

Voltage

0 to Described Continuously Variable
StabilityVoltage: ≤0.01%+2mV
Load: ≤0.0%+2mV
Recover Time≤100μS
Ripple & Noise≤1MVRMSefficent
Temperature Factor≤300PPM/oC

Current

0 to Described Continuously Variable
Current, Load Stability≤0.2%+3mA

Ripple & Noise

≤3mArms

Working
Condition

Line Power Supply

220V±10% 50/60Hz
(Alterable if needed :110±10%50/60Hz)

Operating

Temperature:-10oC~40oC Moisture≤90%

Storage

Temperature:-20oC~80oC Moisture≤80%

         model

specification

MCH-303A
Output voltage0~30V
Output current0~3A
Source regulation1×10-4 +3mV
Load regulation1×10-4 +3mV
Ripple& noise≤1mV(rms)
Display error≤0.5%+1 digit
Weight6.3Kg
Dimension130×165×330mm
