MCH3010D Ac Dc Power Supply 0~30V /10A

● MCH-3010D/3020D
● 2 specifications available

● High stability, digital display, DC power supply
● Overall output protection function

● Current and voltage continously adjustable within nominal value

● Voltage and current output preset
● CC/CV auto switching

SKU: MCH-3010D Categories: Power Supplie Mch Brand: MCH

Description

92 / 100

Powered by Rank Math SEO

MCH3010D Ac Dc Power Supply 0~30V /10A

Brand Name: MCH

Model Number: MCH-3010D

Output Power: 201 – 300W

Output Type: Single

Input Voltage: 110V

Output Voltage: OPTION

Output Frequency: OPTION

Output Current: OPTION

CE: YES

ROSH: YES

CONDITION: BRAND NEW

OTHER CERTIFICATE REQUIRED: YES

OEM: OVER 200 UNIT ORDER = YES

Packaging & Delivery

Packaging Details:	standard export cartons 1.2uints per carton. 2.Inner dimension: 260165300mm 3.Outer dimension: 350330240mm 4.Gross weight: about 12KG/pc
Delivery Detail:	about 20days for above 100units,suply from stock to small order

Specifications
lab power supply 1.0-30V10A ariable single output 2.overall output protection,long time full load working 3.CC/CV auto switch
Lab Power Supply, MCH-3010D DC Power Supply,0-30V/0-10A single output
Specifications:

Voltage		0 to Descripted Continuously Variable
	Stability	Voltage: ≤0.01%+2mV Load: ≤0.0%+2mV
	Recover Time	≤100μS
	Ripple & Noise	≤1MVRMSefficent
	Temperature Factor	≤300PPM/oC
Current		0 to Descripted Continuously Variable
	Current, Load Stability	≤0.2%+3mA
	Ripple & Noise	≤3mArms
Working Condition	Line Power Supply	220V±10% 50/60Hz (Alterable if needed :110±10%50/60Hz)
	Operating	Temperature:-10oC~40oC Moisture≤90%
	Storage	Temperature:-20oC~80oC Moisture≤80%

Model specification	MCH-3010D
Output voltage	0~30V
Output current	0~10A
Source regulation	1×10-4 +3mV
Load regulation	1×10-4 +3mV
Ripple& noise	≤1mV
Display error	≤0.5%+1 digit
