Wanptek KPS6020D 60V/20A High Precision High Power Supply Adjustable LED Dual Display Switching DC Power Supply
Wanptek KPS6020D 60V/20A High Precision High Power Supply Adjustable LED Dual Display Switching DC Power Supply
- Input voltage: AC 220V±10%, 50Hz
- Output voltage: 0 ~ 60V
- Output current: 0 ~ 20A
- Voltage resolution: 0.01V
- Current resolution: 0.01A
- Rugged and durable
- Constant voltage and current
- Protection for Overvoltage, Overcurrent, Overload, Over-temperature, & Short circuit
Wanptek KPS6020D 60V/20A High Precision High Power Supply Adjustable LED Dual Display Switching DC Power Supply
This is Wanptek KPS6020D 60V/20A High precision High Power Adjustable LED Dual Display Switching DC Power Supply. The power supply has a large digital display, which can directly read the voltage. It’s simple in assembly and disassembly, easy to carry, with a storage bag for compact storage. This product is a DC programmable power supply with exquisite appearance, small size, high performance, powerful function and simple operation. The product can display voltage and current at the same time. The output voltage and output current are adjusted by the encoder knob, which can be continuously adjusted between 0 and the nominal value.
Wanptek Wanptek KPS6020D 60V/20A High precision High Power Adjustable LED Dual Display Switching DC Power Supply is from KPS series. This series has a single set of output, high precision double display switch dc power supply. Machines have complete operating protection function, with high performance, low ripple, high stability, light weight, and small volume etc. Current limiting protection can make KPS power supply and load against accidental damage. KPS series power supply with low temperature control circuit, a cooling fan noise is low.
Applications of Wanptek KPS6020D 60V/20A High precision High Power Adjustable LED Dual Display Switching DC Power Supply include Electrolytic plating, Product aging test, Production line test, Charging batteries, Electronic device testing, Laboratory research and development test, School teaching experiment, Telecom Power, etc. It is suitable for testing in aerospace and defense, consumer electronics, computers and peripherals, communications, semiconductors, solar energy and automotive electronics.
Features:
- Output voltage: 0-nominal voltage continuously adjustable
- Output current: 0-nominal value current continuously adjustable
- Protection for Overvoltage, Overcurrent, Overload, Over-temperature, Short circuit
- Rugged and durable
- Constant voltage and current
- Smart fan
- Low ripple & Low noise
- Voltage stabilization, current limiting, simple operation
- Highly efficient, low ripple
- Flexible operation and convenient use
- Double potentiometer more precise adjustment
- Small size, light weight, suitable for work surface use and rack installation;
- Voltage and current preset, OUT output function
Specification:
| Voltage resolution | 0.01V |
|---|---|
| Current resolution | 0.01A |
| Header display | 0.56 inch white four-digit digital tube display Display accuracy: 0.5%±3 words Display resolution: voltage 0.01V, current 0.01A |
| Steady flow state CC | Current stability:0.5%±20mA Load stability:0.5%±20mA Ripple current:≤0.5% Vp-p Temperature Coefficient:≤100ppm/℃ |
| Regulated state CV | Voltage stability:0.5%±20mV Load stability:0.5%±20mV Ripple voltage:≤0.5% Vp-p |
| Rise Time | No load≤15ms Fully loaded≤30ms |
| Dynamic response time | ≤2ms |
| Storage temperature | -10℃～70℃; Relative humidity:<70%RH |
| Net/gross Weight (KG) | 3 |
| Dimension (lxwxh) mm | 275 x 200 x 105 |
| Operating environment | 0℃～40℃; Relative humidity:<80%RH |
| Shipping Weight | 3.7 kg |
| Shipping Dimensions | 37 × 27 × 18 cm |
