UNI-T Ut205A+ 1000A Ac Clamp Meter
UNI-T Ut205A+ 1000A Ac Clamp Meter
₨9,775
UT205A+/UT206A+ 1000A AC clamp meters are reliable and portable tools for electronics and electrical maintenance. Featuring a lightweight and slim design, and backlight for working in dark environments. These meters also feature duty cycle, NCV, MAX/MIN, and Inrush current measurement.
Buy Now
Add to cart
| Weight | 0.5 kg |
|---|
Features
1. 1000A AC current measurement
2. 1000V AC/DC voltage measurement
3. 600A inrush current measurement (UT206A+)
4. Temperature (UT206A+)
5. NCV (UT206A+)
6. ACV frequency 10Hz～10kHz
7. Jaw opening: 45mm
8. Resistance / capacitance / frequency measurement
9. Auto range / backlight / low battery indication
10. Continuity / diode / duty cycle
11. MAX/MIN
12. Data hold / flashlight / relative mode
13. Auto power off
14. CAT II 1000V/CAT III 600V
Specifications
| Specifications | Range | UT205A+ |
| AC current (A) | 1000A | ±(1.5%+5) |
| Inrush current (A) | 600A | |
| AC voltage (V) | 1000V | ±(1.0%＋2) |
| ACV frequency (Hz) | 10Hz～10kHz | ±(1.0%＋5) |
| DC voltage (V) | 1000V | ±(0.7%＋3) |
| Resistance (Ω) | 40MΩ | ±(0.8%+2) |
| 60MΩ | ||
| Capacitance (F) | 40mF | ±(4%+5) |
| 60mF | ||
| Frequency (Hz) | 10.00Hz～10.00MHz | ±(0.1%+4) |
| Temperature (℃/℉) | –40℃～1000℃/–40℉～1832℉ | |
Model And Comparision
| Specifications | Range | UT205A+ | UT206A+ |
| AC current (A) | 1000A | ±(1.5%+5) | ±(1.5%+5) |
| Inrush current (A) | 600A | ±(5%+10) | |
| AC voltage (V) | 1000V | ±(1.0%＋2) | ±(1.0%＋2) |
| ACV frequency (Hz) | 10Hz～10kHz | ±(1.0%＋5) | ±(1.0%＋5) |
| DC voltage (V) | 1000V | ±(0.7%＋3) | ±(0.7%＋3) |
| Resistance (Ω) | 40MΩ | ±(0.8%+2) | |
| 60MΩ | ±(0.8%+2) | ||
| Capacitance (F) | 40mF | ±(4%+5) | |
| 60mF | ±(4%+5) | ||
| Frequency (Hz) | 10.00Hz～10.00MHz | ±(0.1%+4) | ±(0.1%+4) |
| Temperature (℃/℉) | –40℃～1000℃/–40℉～1832℉ | ±4℃/±5℉ | |
| Features | |||
| Display count | 4099 | 6099 | |
| Jaw opening | 45mm | 45mm | |
| Auto range | √ | √ | |
| Duty cycle | √ | √ | |
| NCV | √ | ||
| Diode test | √ | √ | |
| Continuity | √ | √ | |
| Low battery indication | ＜2.5V approximately | √ | √ |
| Data hold | √ | √ | |
| Auto power off | Approximately 15 minutes | √ | √ |
| Max/Min | √ | √ | |
| Flashlight | √ | √ | |
| Backlight | √ | √ | |
| Safety rating | CAT II 1000V/CAT III 600V | √ | √ |
| General Characteristics | |||
| Power | AAA 1.5V x 2 | ||
| Standard accessories | Test leads, batteries, temperature probe(UT206A+), English manual | ||
| Product color | Red+Gray | ||
| Product net weight | 235g (Including batteries) | ||
| Product size | 242×76.5x52mm | ||
| Standard individual packing | Gift box，carrying bag | ||
| Standard quantity per carton | 20 pcs | ||
| Standard carton measurement | 420*290*280mm | ||
