Yihua 948-III Soldering Station

Sold: 0

17,225

17,225

Buy Now
Add to cart

27 / 100
  • Desoldering: This desoldering station, with its 0.05MPA suction force and adjustable temperature from 716~896℉, provides easier through-hole component desoldering experience. This desoldering tool is especially suitable for through-hole desoldering operations for in-line sockets, LCD display, LED Nixie Tube and more.
  • Soldering: The soldering station ‘s 110W heating element can heat up fast during use. Temperature is adjustable from 392~896°F. When heating, the built-in PID program will detect and compensate the temperature loss every 20 milliseconds to achieve fast temperature recovery. This soldering iron station can apply to most soldering situations, even for larger solder joints.
  • 2 in one integrated. This multi-station allows you to use soldering station and desoldering station at the same time. When the solder joints require slightly more heat, you can use the soldering iron and desoldering gun together to heat up the solder joint fully before extracting the melted solder with the desoldering tool.
  • Complete set of accessories. 100% metallic soldering iron stand ensures sufficient weight and width to store and support desoldering gun and soldering iron, thus preventing them from tipping over on your workbench. Full-fledged accessories kit including cleaning sponge, cleaning pins, filter springs, ceramic filters, carbon filters and solder storage chamber helps you collect and clean the residues with ease.
  • This 2 in 1 soldering and desoldering tool is covered by our USA exclusive 1-Year product warranty, and our technical support team has your back with our 24-Hour support. NOTE: this product is rated for 110~127V USA Specification, DO NOT connect this device to a 220V power socket

Features

27 / 100

Soldering Station



  • High Performance Heating Element
  • Temperature Range: 392~896°F
  • Temperature Stabilization:PID Program
  • Able to solder larger joints



Desoldering Station



  • Temperature range: 716~896°F
  • Temperature Stabilization:PID Program
  • Suction force: 0.05 MPA
  • Easier and quicker desoldering



2-IN-1 Integrated Holder



  • Wholly-metal built
  • Greater safety and stability to support two tools
  • Compact and space-saving design



Specifications

27 / 100
Model number 948-III
Rated voltage range 110V~127V AC
Maximum power 250W
Rated power 74W
Main unit dimensions L248×W150×H126mm±5mm
Operating ambient temperature 0~40°C/32~104°F
Desoldering Station
Temperature range 380-480°C/716-896°F
Display LCD
Tip to ground resistance <2 Ohms
Vacuum pressure 0.05 Mpa
Soldering Station
Temperature range 200~480°C/392~896°F
Display LCD
Tip to ground resistance <2 Ohms

Detail Images

27 / 100

using the WEP 948-III for desoldering
