Basic Features

  • ■ Suitable for elevator speed measurement of high building
  • ■ 2 independent displays
  • ■ Analog output teminal to record measuring data
  • ■ 2 external hold terminals for remote control
  • ■ Memory function (max.10sets data)
  • ■ Averaging count function
  • ■ Easy to read LED displays
  • ■ Auto power off (3min.) (extendable to 1hr.)
  • ■ Low battery power alarm







Specifications

11 / 100
Measuring
range
Linnear velocity:0.1-2000.0(m/min)
Rotation sspeed :1-20000(r/min)
Distance:0-999(mm)
Accuracy +2dgt
Sampling time 0.2 sec Measuring time 0.01 sec Anlogoutput DCo-2VAnaog ouptut acceracy:+(0.8%+2mV) Data hold CH1/CH2/Max. Vvalue Indepeendent functions
CH1/CH2:Hold by main unit panel or exteernal triggering
Battery LR6X4 Fuse /5X20mm (250V/0.5A) Size/Mass H174XW50XD50mm/approx.510g Standardaccessoriesincluded Speed ring thickness 10mm (SE-10)X1>Speed ring thickness 0.99mm (SE-10)X1
Hold input cable (SE-10)X2
Analoge output (SE-L-O)X1
Hex wrenchX1,Carryinglnstruction manual
