Yihua YH-938D Smd Hot Tweezers Desoldering Soldering Station - Variety House

Yihua YH-938D Smd Hot Tweezers Desoldering Soldering Station

17,500

Ships In: 1-3 Days
Delivery Area: Nationwide
Shipped By: Variety House

main unit + power cord
guide
soldering iron
soldering iron holder

17,500

Buy Now
Add to cart
SKU: YH-938D-SMD Categories: Brand:
8 / 100
  • Inner box size                    26.3*21.6*16.3CM
  • Outer carton box size        45.5*28*51.5CM
  • Q’TY                                  6PCS/CTN
  • Goods net weight              3.25KG/PC
  • Outer carton weight           19.5KG

CHARACTERISTIC

8 / 100

1.The machine has been upgraded with a new backlit panel using the newest LCD technology, offering a beautiful and elegant look, and accurately displaying the temperature of the tweezers and soldering iron as well as other functions.
2.Adopt microcomputer control,warming-up quickly.
3.High-quality resistance good for long service life.
4.This product is ESD-protected.
5.soldering iron handle using silicone material.
6.The machine uses brushed aluminum panels, which as well as looking attractive, are also compact and space-saving.
7.Uses PID programmable temperature control technology, applying sophisticated PID programming into the machine to rapidly track, test, and correct the actual temperatures of the tweezers and soldering iron. Rapid temperature compensation reduces temperature error. Temperature stability and temperature compensation speed are significantly better than similar products.



8.Internal design uses SMT double-sided panels, producing a neat arrangement; signal flow is clear, and the stability and operational safety of the machine has been further strengthened. The machine can be used in a number of harsh environments.
9.Longer soldering iron handle line,it has 1.5 meter.
10.The handle for the soldering tweezers has a unique design, and is paired with a unique soldering iron stand. The soldering tweezer station is ideal for use soldering small plates and small IC. Due to its parallel design, the soldering tweezer station can be heated and used for soldering at the same time.
11.Unique handle model and soldering iron holder humanity design.

PARAMETERS

8 / 100
MODEL938D
Power consumption90W
Temperature Range100°C~480°C/212°F~896°F
Display typeLCD
Temperature stability±2°C (static)
Heater voltageAC 24V ±10% 50Hz
Tip of ground resistance<2ohm
Tip of ground Voltage<2mv
Working temperature0~40°C/32°F~104°F
Storage temperature-20°C~80°C/-4°F~176°F
G.w2.72kg/cps
Outer carton quantity6pcs/ctn
