Gopher CPS-3010 Digital Adjustable DC Power Supply 0-30V ~ 10A

Feature:

The use of microprocessor (MCU) control, high cost
High power density, compact appearance
Aluminum housing, very low electromagnetic interference
The encoder is used to adjust the voltage and current settings quickly and accurately
Four digital ammeter and three digital voltmeter
Soft-start function, no overshooting
High efficiency and efficiency up to 88%
Low ripple noise, peak ripple is less than 30mV
Output ON / OFF switch
Input operating voltage 220VAC / 110VAC switch
Lock button, the output switch button and adjust the lock knob to prevent accidental changes
Intelligent protection: Output short-circuit protection, tracking over-voltage protection (Tracking OVP), tracking over-current protection (Tracking OCP), over-temperature protection (OTP)

Specifications:

Operating voltage range: 198 – 264Vac
Operating frequency range 45 – 65Hz
Output voltage range 0 – 30V
Output current range 0 – 10A
Efficiency (220Vac, full load) ≥ 88%
Full load input current (220Vac) ≤2.3A
No-load input current (220Vac) ≤ 120mA
Voltage meter accuracy ≤ 0.3% + 1 digits
Ammeter accuracy ≤ 0.3% +3 digit

Constant pressure state
Load regulation (0-100%) ≤ 30mV
Input voltage regulation rate (198-264Vac) ≤ 10mV
Ripple noise (Peak-Peak) ≤ 40mV
Ripple noise (r.m.s) ≤ 5mV
Set the accuracy of ≤ 0.3% +10 mV
Transient response time (50% -100% rated Load) ≤ 1.0ms

Constant current state
Load Regulation (90% -10% Rated Voltage) ≤ 100mA
Input voltage regulation rate (198-264Vac) ≤ 50mA
Ripple current noise (peak-to-peak) ≤ 100mAp-p
Setting accuracy ≤ 0.3% + 20mA
Dimensions (width × height × depth) 120 × 55 × 240mm
Net weight 1.2KG
